122A 型閥門是一種用于開關應用的大容量、經濟劃算的三通氣動切換閥。 該閥門可以用于分流或合流氣態應用，氣液分流液體服務和合流液體應用。

便于安裝

易于泄漏檢測

易于維護

Fisher122A型三通切換閥規格

閥體尺寸和端口連接方式連接 A 和 C：3/4 與 1 NPT，連接 B：3/4 NPT

最大入口壓力150 psig / 10.3 bar

出口壓力范圍3 至 150 psig / 0.2 至 10.3 bar

溫度適用范圍-20 至 150°F / -29 至 66°C

單位名稱：廣州奧麗斯特燃?xì)庠O(shè)備有限公司

單位地址：廣東省廣州市天河區珠村東環路110號珠園大廈402室

Type 122A valve is a high-capacity, economical three-way pneumatic switching valve for on-off applications. This valve can be used for diverging or converging gaseous service, diverging liquid service with gas-loaded liquids, and converging liquid service.

Features

Convenient Installation

Easy Leak Detection

Easy Maintenance

Specifications

Body Size and End Connection Style

Connections A and C: 3/4 and 1 NPT
Connection B: 3/4 NPT

Maximum Inlet Pressure

150 psig / 10.3 bar

Outlet Pressure Range

3 to 150 psig / 0.2 to 10.3 bar

Temperature Capabilities

-20 to 150F / -29 to 66C
